This Male Elbow High Speed Brass Rotary Fitting was the latest invention high quality .It was Made of high-quality plastics and nickel-plated copper for durable use .We devoted our selves to air pneumatic many years,covering most of Europe and the Americas market.We are expecting become your long-term partner in china.
Plastic material, keep strength and light weight at the same time.The elastic card spring is inserted into the tracheal sleeve to complete the connection.When disconnected, the tracheal sleeve will be pressed. •Made of high-quality plastics and nickel-plated copper for durable use
• Type: Quick Connect Fitting Connector
• Advantages: Easy installation and disassembly, good sealing performance
• Fluid type: air, vacuum
• Operating Pressure: 0-0.9Mpa
• Proof pressure:1.32Mpa
• Working Temperature: 0-60°C
• Applicable pipe: PU/PA/PE/PVC
| Fluid | Compresses Air, if liquid please ask for technical support |
| Proof Pressure | 1.32Mpa (1.35kgf/cm2) |
| Working Pressure Range | 0~0.9Mpa (0~9.2kgf/cm2) |
| Ambient Temperature | 0~60℃ |
| Applicable Pipe | PU Tube |
| Material | Brass |
| Model | ØD | R | F | C | B | P2 | A | H | RPM |
| NHRC 4-M5 | 4 | M5 | 26 | 18 | 52 | 14 | 3.5 | 15 | 1500 |
| NHRC 4-M6 | 4 | M6/8 | 26 | 18 | 53.5 | 14 | 6 | 15 | 1500 |
| NHRC 4-01 | 4 | PT1/8 | 26 | 18 | 52 | 14 | 8 | 15 | 1500 |
| NHRC 6-M5 | 6 | M5 | 24.5 | 18.5 | 51.5 | 14.5 | 3.5 | 15 | 1200 |
| NHRC 6-01 | 6 | PT1/8 | 24.5 | 18.5 | 51 | 14.5 | 8 | 15 | 1200 |
| NHRC 6-02 | 6 | PT1/4 | 24.5 | 18.5 | 52 | 14.5 | 10 | 15 | 1200 |
| NHRC 8-01 | 8 | PT1/8 | 26 | 23 | 57.5 | 15 | 8 | 17 | 1200 |
| NHRC 8-02 | 8 | PT1/4 | 26 | – | 57 | 15 | 11 | 17 | 1200 |
| NHRC 8-03 | 8 | PT3/8 | 26 | – | 56.5 | 15 | 11 | 17 | 1200 |
| NHRC 10-02 | 10 | PT1/4 | 30 | – | 68 | 18.5 | 11 | 24 | 1000 |
| NHRC 10-03 | 10 | PT3/8 | 30 | 22 | 65 | 18.5 | 11 | 24 | 1000 |
| NHRC 10-04 | 10 | PT1/2 | 30 | 22 | 66 | 18.5 | 12 | 24 | 1000 |
| NHRC 12-02 | 12 | PT1/4 | 31 | – | 69 | 19 | 11 | 24 | 1000 |
| NHRC 12-03 | 12 | PT3/8 | 31 | – | 66 | 19 | 11 | 24 | 1000 |
| NHRC 12-04 | 12 | PT1/2 | 31 | – | 67 | 19 | 12 | 24 | 1000 |
