This Pressure Controller was the latest invention high quality .We devoted our selves to air pneumatic many years,covering most of Europe and the Americas market.We are expecting become your long-term partner in china.
1.lt can be used not only in the freezing medium like Freon, but also in air and liquid( Allowable temperature of liquid: -10- +120);
2.Multi-touch Switch Function;
3.With SPDT design;
4.Micro switch ensure the reliable switch function;
5.Manual control, no need any tools to achieve electric contact function;6.Facile mounting plate could be applied for different mounting situations.
Various parameters can be provided
| Model | SNS-103 | SNS-106 | SNS-110 | SNS-120 | SNS-130 | |
| Regulating range(Mpa) | Min | 0.03 | 0.1 | 1 | 5 | 5 |
| Max | 0.3 | 0.6 | 1 | 2 | 3 | |
| Output Pressure(Mpa) | Min | 0.035 | 0.06 | 0.1 | 2 | 0.3 |
| Max | 0.2 | 0.4 | 0.3 | 0.5 | 1 | |
| Setting Value(Mpa) | off(on) | 0.05 | 0.1 | 0.4 | 1.5 | 2 |
| on(off) | 0.15 | 0.3 | 0.6 | 1.2 | 1.5 | |
| Max.Working Pressure(Mpa) | 1.1 | 1.65 | 1.65 | 4 | 4 | |
